ARB Winches for Land Rover Defender
Equip your Land Rover Defender with the ultimate self-recovery tool. The ARB Winch range combines precision engineering with modern vehicle integration, delivering unmatched pulling power without sacrificing your vehicle’s styling or functionality
Advanced Drive & Braking Technology At the heart of the ARB Winch is a purpose-built series-wound motor paired with a cutting-edge, 4-stage gearbox featuring 2-stage planetary and 2-stage spur hardened steel gearsets
For absolute safety during steep descents or heavy recoveries, the winch features a gearbox-mounted, 100% load-holding proportional friction brake
Seamless Integration & Controls Say goodbye to messy external wiring. The built-in motor control unit utilizes a direct-connection 500Amp Albright DC contactor to boost electrical efficiency
Every winch comes equipped with a Dual Connection Wireless Remote—a compact hand controller that offers the ultimate flexibility of a 5m (16ft) wired lead or a massive 40m (131ft) wireless operational range
Choose Your Model
| Specification | ARB 10,000lb Winch (ARW100SA) | ARB 12,000lb Winch (ARW120SA) |
| Rated Line Pull |
10,000 lbs (4,536 kg) |
12,000 lbs (5,443 kg) |
| Motor Output |
4.0 kW / 5.3 HP (Tuned 12V) |
4.3 kW / 5.7 HP (Tuned 12V) |
| Synthetic Rope |
10mm x 28m (Grey) |
11mm x 24m (Grey) |
| Max Line Speed |
60 ft/min (18.5 m/min) |
65 ft/min (20 m/min) |
| Fitted Weight |
73.5 lbs (33.3 kg) |
76 lbs (34.5 kg) |
| Best Used For | Defender 90 & lighter overland setups. | Defender 110/130 & fully laden expedition rigs. |
Shared Premium Features:
- IP68 Waterproof Rating: Both the winch motor and the gearbox are fully sealed against water, mud, and dust ingress
- Forged Hawse Fairlead: Supplied with an ultra-strong, forged 6061 aluminium fairlead to protect your synthetic rope from abrasion
- Flexible Clocking Positions: Designed to fit tight spaces with a rotatable gearbox (16 positions in 22.5° increments) and a rotatable motor (5 positions in 45° increments)
- Robust & Lightweight: Built using premium aluminium alloy housings engineered for maximum structural strength without overloading your front suspension
Installation Note: The ARB Winch comes pre-wired with pre-set gearbox positioning out of the box to ensure quick and easy fitment into the most common Defender winch bumpers
