Differential Guards

We design and manufacture Land Rover Defender Differential Guards. Diff guards protect vehicle differentials from rock and tree root damage, etc. Fits all standard Land Rover axles front or rear – all Defenders 90, 110, 130, series II/III, Discovery and Range Rover Classic. We have Heavy Duty 5mm thick versions and standard 3mm versions – although we are now only selling the 3mm on eBay, and the 5mm here.

High tensile carbon steel with high quality zinc galvanised plating. High strength construction with superior clean welding laser-cut.  Very easy to fit without any drilling, and it can be transferred to other vehicles. The kits include two 8 mm x 70 mm cylindrical allen key bolts with heavy gauge zinc plating and two self-locking nuts with nylon inserts.

1107mm Camper Style Side Window - DARK tint

SKU DEF1107x477
In stock
Product Details

1107mm Camper-Style Side Window - DARK tint, for Land Rover Defender and other vehicles

Variety of uses where increased access, light and ventilation is needed but not at the expense of security. Use as replacement or as a hard-top conversion.

Please Note: These windows can be retro-fitted to all Defender window apertures including 50/50 radius corners on 200tdi/300Tdi/TD5 and 50/70 radius corners on Tdci Puma.

If your vehicle is a hardtop and does not currently have rear side windows then our side windows can be fitted irrespective of the radius of your aperture corners.

We also have another version which is narrower and not a "standard size" Land Rover window DEF810x477.

Includes Internal Bezel Trim (aluminium L section 20mm x 20mm, black powder-coat paint). This bezel can be used as a template to cut out the aperture.

Once you have cut the correct shaped aperture, you will need rivets and silicone sealant to attach the window.

If you need it completely wide open the gas strut brackets can be unscrewed from the frame.

Originally designed for use on the side of a vehicle however, it can also be used on the roof of a vehicle as a sun roof, in this case the drain holes must be blocked with silicone sealant.

  • SOLD as SINGLE WINDOWS (Price is NOT for a pair)
  • Includes two Gas Struts for smooth opening and closing
  • Two handle locking with keys
  • The maximum amount these windows open is as seen in the above photo and is 200mm from the vehicle body.
  • Measurements: 1107mm x 477mm external max
  • The size of the aperture you need to cut out is 1057mm x 427mm - which is the Land Rover standard size for Defender rear side windows
  • The internal area is 1017mm x 387mm (see diagram)
  • The Radius of the cut-out aperture needs to be 76mm (see diagram)
  • Black powder-coat painted aluminium frame
  • Made to original Land Rover quality - BUT they do not rattle or leak
  • Standard size replacement
  • Includes rubber seal and internal bezel
  • E43 4mm toughened safety glass
  • 70% No-Light transmission Dark Tint
  • Factory prepared tint - not a stuck on film
  • Suitable for use with factory fitted internal trims.
  • Easy to fit DIY
  • Fitting service also available - just call

This Masai expedition camper window will fit with standard Defender TD5 and TDCI Puma internal window trims. If you do not have the trims on your vehicle you can also buy these from our website. Alternatively you can use the inner bezel 20x20 mm supplied with our windows.

Can be fitted to the side of:

  • Land Rovers and other 4x4
  • Other Shooting/Leisure vehicles
  • Trucks with Sleeping Pods
  • Coaches and Lorries
  • Containers/Sheds in Gardens
  • Horseboxes
  • Motor Caravans / Motor Home
  • Towed Caravans
  • Mobile Exhibition Trailer
  • Porta-cabins / Mobile Buildings / Other Enclosure
  • Sailing Boats and Narrow Boats as a Deck Hatch possibly - call to discuss

Optional extras

  1. Rivets and Sealant

Download ......Masai Defender side windows Fitting Instructions

These fitting instructions are NOT actually for this specific window but the principles are the same.
